KNX control elements and application parameters
Application "Logical functions"
Product manual 2CKA00xx73xxxxx
206
– 2-byte value [0 - 65535]: A value is sent as 2-byte value without a sign, e.g. actuating
value or time interval. No additional parameters available.
– 2-byte floating point: A value is sent as 2-byte floating point value, e.g. a temperature
value, a time duration, a performance or a consumption value. No additional parameters
available.
– 4-byte value [-2147483648 - 2147483647]: A value is sent as 4-byte value with a sign,
e.g. actuating value or time difference. No additional parameters available.
– 4-byte value [0 - 4294967295]: A value is sent as 4-byte value without a sign, e.g.
actuating value. No additional parameters available.
– 14-byte text: Makes it possible to send a text. No additional parameters available.
Saving input signal during blocking:
Options: Deactivated
Activated
See the explanation above.
– Temperature comparator: This function can be used to compare temperature values. The
following parameters are displayed:
Name of channel:
Options: <Name>
Naming of the channel. The length of the name is limited to 60 characters.
Type of comparator:
Options: Temperature with a constant
2 temperatures
This function can be used to compare two temperatures. Or a temperature can be
compared with an internal specified temperature value (constant).
– Temperature with a constant: This function makes an input available with a 2-byte
communication object. On this object temperature telegrams are received and
compared, which are sent from a KNX temperature sensor for example.
The following parameters are displayed:
Input 2 [°C]:
Options: Setting options from -30 - +70
This parameter is used to specify the value with which the temperature at input 1 is to
be compared.
Hysteresis:
Options: Setting options from 0.5 - 10
– 2 temperatures: This function makes two separate inputs with 2-byte communication
objects available. On these objects temperature telegrams are received and compared
with each other, which are sent from KNX temperature sensors. No additional
parameters available.
