KNX control elements and application parameters
Application "Logical functions"
Product manual 2CKA00xx73xxxxx
207
Object type of the output:
Options: 1 bit
1 byte
The parameter is used to specify whether the output object sends a 1-bit value (0/1) or a 1-
byte value (0 - 255).
– 1 bit: The following supplementary parameters are available:
Sending value when input 1 > input 2:
Options: OFF telegram
ON telegram
The parameter is used to specify which output object is sent (ON or OFF) when input 1
is logically larger than input 2.
Sending value when input 1 < input 2:
Options: OFF telegram
ON telegram
The parameter is used to specify which output object is sent (ON or OFF) when input 1
is logically smaller than input 2.
– 1 byte: The following supplementary parameters are available:
Sending value when input 1 > input 2:
Options: Setting options from 0 - 255
The parameter is used to specify which output object is sent when input 1 is logically
larger than input 2.
Sending value when input 1 < input 2:
Options: Setting options from 0 - 255
The parameter is used to specify which output object is sent when input 1 is logically
smaller than input 2.
Telegram is sent at:
Options: Change output
Output 1 is larger than input 2
Output 1 is smaller than input 2
A telegram is sent when the selected condition is met.
Cyclic sending of output:
Options: Deactivated
Activated
The parameter is used to specify whether the output telegram is sent in cycles.
– Deactivated: No additional parameters available.
– Activated: The following parameter appears:
