KNX control elements and application parameters
Application "Logical functions"
Product manual 2CKA00xx73xxxxx
208
Cycle time:
Options: Setting options from 00:00:01 - 00:30:00
The parameter is used to specify the cycle time (hh:mm:ss).
– Status converter: This function is used to convert an input value into a 14-byte text or divide
it into several 1-bit telegrams. The following parameters are displayed:
Name of channel:
Options: <Name>
Naming of the channel. The length of the name is limited to 60 characters.
Type of converter:
Options: 1 bit -> text
1 byte -> text
1 byte -> 8x1 bit
2 byte -> 16x1 bit
See the explanation above.
– 1 bit -> text: A 1-bit value is converted into text. The following parameter appears:
Number of inputs:
Options: Setting options from 1 - 4
The parameter is used to set the number of available inputs. The following parameter
appears:
Using value xxxx:
Options: Deactivated
Activated
The parameter is used to specify whether the signal is used for the conversion into text.
– Deactivated: No additional parameters available.
– Activated: The following parameter appears:
Text for value xxxx:
Options: <Text>
Naming of the value. The length of the text is limited to 15 characters.
Notice
How many "Use value xxxxx" parameters and "Text for value xxxx"
are displayed depends on the setting of the "Number of inputs"
parameter.
– 1 byte -> text: A 1-byte value is converted into text. The following parameter appears:
Number of texts:
Options: Setting options from 1 - 16
The parameter is used to set the number of values to be converted into text. The
following parameters are displayed:
