ABB SmartTouch i-bus KNX User Manual

Communication objects
Application "Internal RTC"
Product manual 2CKA00xx73xxxxx
│
260
Name Object function Length Data type
Flags
K L S U A
Status converter - Output 2 Output 1 bit
[1.002]
Boolean
K - S U A
Status converter - Output 3 Output 1 bit
[1.002]
Boolean
K - S U A
Status converter - Output 4 Output 1 bit
[1.002]
Boolean
K - S U A
Status converter - Output 5 Output 1 bit
[1.002]
Boolean
K - S U A
Status converter - Output 6 Output 1 bit
[1.002]
Boolean
K - S U A
Status converter - Output 7 Output 1 bit
[1.002]
Boolean
K - S U A
Status converter - Output 8 Output 1 bit
[1.002]
Boolean
K - S U A
Status converter - Output 8
(MSB)
Output 1 bit
[1.002]
Boolean
K - S U A
Status converter - Output 9 Output 1 bit
[1.002]
Boolean
K - S U A
Status converter - Output 10 Output 1 bit
[1.002]
Boolean
K - S U A
Status converter - Output 11 Output 1 bit
[1.002]
Boolean
K - S U A
Status converter - Output 12 Output 1 bit
[1.002]
Boolean
K - S U A
Status converter - Output 13 Output 1 bit
[1.002]
Boolean
K - S U A
Status converter - Output 14 Output 1 bit
[1.002]
Boolean
K - S U A
Status converter - Output 15 Output 1 bit
[1.002]
Boolean
K - S U A
Status converter - Output 16
(MSB)
Output 1 bit
[1.002]
Boolean
K - S - A
Time function - Input Input 1 bit
[1.001]
Switching
K - S - A
Time function - Output Output 1 bit
[1.001]
Switching
K - S U A
Time function - staircase lighting
(sec.)
Input 2 bytes
[7.005]
Time (s)
K - S U A
Time function - Switch-on delay
(sec.)
Input 2 bytes
[7.005]
Time (s)
K - S U A
Internal RTC
Heating control value Output 1 bit
[1.001]
Switching
K - - U -
Additional-stage heating Output 1 bit
[1.001]
Switching
K - - U -
Cooling control value Output 1 bit
[1.001]
Switching
K - - U -
Additional-stage cooling Output 1 bit
[1.001]
Switching
K - - U -
On/off confirmation (Master) Output 1 bit
[1.001]
Switching
K L S U A

