ABB SmartTouch i-bus KNX User Manual

Communication objects
Application "Internal RTC"
Product manual 2CKA00xx73xxxxx
│
261
Name Object function Length Data type Flags
K L S U A
Actual temperature weighted Output 2 bytes
[9.001]
Temperature
(°C)
K - S U A
External actual temperature Input 2 bytes
[9.001]
Temperature
(°C)
K - S U A
External actual temperature 2 Input 2 bytes
[9.001]
Temperature
(°C)
K - S U A
Fault, actual temperature
(master)
Output 1 bit
[1.001]
Switching
K L - U -
Current setpoint Output 2 bytes
[9.001]
Temperature
(°C)
K - - U -
Normal operating mode (master)
Input/
Output
1 byte
[20.102]
HVAC mode
K - S U A
Override operating mode
(Master/Slave)
Input 1 byte
[20.102]
HVAC mode
K - S U A
Window contact (master/slave)
Input/
Output
1 bit
[1.001]
Switching
K - S U A
Presence detector
(master/slave)
Input/
Output
1 bit
[1.001]
Switching
K - S U A
Heating status Output 1 bit
[1.001]
Switching
K - - U -
Cooling status Output 1 bit
[1.001]
Switching
K - - U -
Basic load Input 1 bit
[1.001]
Switching
K - S U A
Heating/cooling switchover Output
[1.100]
Heating/cooling
Confirm fan manually (master) Output 1 bit
[1.001]
Switching
K L - U -
Fan speed /
level
Output 1 byte
[5.001]
Percent
(0 - 100%)
K - - U -
Basic setpoint Input 2 bytes
[9.001]
Temperature
(°C)
K - S U A
Resetting manual setpoints Input 1 bit
[1.001]
Switching
K - S - A
Dew point alarm Input 1 bit
[1.001]
Switching
K - S U A
Condensation / fill level alarm
(Master/Slave)
Input/
Output
1 bit
[1.005]
Alarm
K - S U A
Outside temperature
for summer compensation
Input 2 bytes
[9.001]
Temperature
(°C)
K - S U A
Summer compensation active Output 1 bit
[1.001]
Switching
K - - U -
Temperature calibration Input 2 bytes
[9.001]
Temperature
(°C)
K - S - A

