ABB SmartTouch i-bus KNX User Manual

Communication objects
Application "Internal RTC"
Product manual 2CKA00xx73xxxxx
│
262
Name Object function Length Data type Flags
K L S U A
Setpoint display (master) Output 2 bytes
[9.001]
Temperature
(°C)
K L - U -
Request set value (master) Input 2 bytes
[9.001]
Temperature
(°C)
K - S - A
Confirm setpoint (master) Output 2 bytes
[9.001]
Temperature
(°C)
K L - U -
Request fan speed level
manually (slave)
Output 1 bit
[1.010]
Switching
K - - U -
Request fan speed level
manually (master)
Input 1 bit
[1.001]
Switching
K - S - A
Request fan speed level (slave) Output 1 byte
[6.010]
Counting pulses
(-128 - 127)
K - - U -
Request fan speed (master) Input 1 byte
[5.001]
Percent
(0 - 100%)
K - S - A
Confirm fan speed level (slave)
Input/
Output
1 byte
[6.010]
Counting pulses
(-128 - 127)
K - S U A
Confirm fan speed (master) Output 1 byte
[5.001]
Percent
(0 - 100%)
K L - U -
Controller RHCC status Output 2 bytes [22,101] K - - U -
Controller HVAC status (master) Output 1 byte
[5.001]
Percent
(0 - 100%)
K L - U -
Heating temperature limit basic
stage
Input 2 bytes
[9.001]
Temperature
(°C)
K - S - A
Heating temperature limit
additional stage
Input 2 bytes
[9.001]
Temperature
(°C)
K - S - A
Cooling temperature limit basic
stage
Input 2 bytes
[9.001]
Temperature
(°C)
K - S - A
Cooling temperature limit
additional stage
Input 2 bytes
[9.001]
Temperature
(°C)
K - S - A
Comfort heating setpoint Output 2 bytes
[9.001]
Temperature
(°C)
K - S - A
Standby heating setpoint Input 2 bytes
[9.001]
Temperature
(°C)
K - S - A
Economy heating setpoint Input 2 bytes
[9.001]
Temperature
(°C)
K - S - A
Heating setpoint for building
protection
Input 2 bytes
[9.001]
Temperature
(°C)
K - S - A
Comfort cooling setpoint Input 2 bytes
[9.001]
Temperature
(°C)
K - S - A

