ABB SmartTouch i-bus KNX User Manual

Communication objects
Application "Internal RTC"
Product manual 2CKA00xx73xxxxx
│
263
Name Object function Length Data type Flags
K L S U A
Economy cooling setpoint Input 2 bytes
[9.001]
Temperature
(°C)
K - S - A
Cooling setpoint for building
protection
Input 2 bytes
[9.001]
Temperature
(°C)
K - S - A
Setpoint error Output 1 bit
[9.001]
Temperature
(°C)
K - - U -
Current HVAC operating mode Output 1 byte
[20.102]
HVAC mode
K - S U A
Switch
Value 1 [send]
Input/
Output
1 bit
[1.001]
Switching
K - S U A
Value 2 [send] Output 1 bit
[1.001]
Switching
K - - U -
Status value [receive] Input 1 bit
[1.001]
Switching
K - S - A
Block Input 1 bit
[1.002]
Boolean
K - S - A
Rocker switch
Value 1 [send]
Input/
Output
1 bit
[1.001]
Switching
K - S U A
Value 2 [send] Output 1 bit
[1.001]
Switching
K - - U -
Status value [receive] Input 1 bit
[1.001]
Switching
K - S - A
Block Input 1 bit
[1.002]
Boolean
K - S - A
Dimmer
Switch
Input/
Output
1 bit
[1.001]
Switching
K - S U A
Dimming Output 3 bit
[3.007]
Dimmer step
K - S U -
Value
Input/
Output
1 byte
[5.001]
Percent
(0 - 100%)
K - S U A
Switch status Input 1 bit
[1.001]
Switching
K - S - A
Status value Input 1 byte
[5.001]
Percent
(0 - 100%)
K - S - A
Block Input 1 bit
[1.002]
Boolean
K - S - A
Dimmer slider
Switch
Input/
Output
1 bit
[1.001]
Switching
K - S U A
Value
Input/
Output
1 byte
[5.001]
Percent
(0 - 100%)
K - S U A

