ABB SmartTouch i-bus KNX User Manual

Communication objects
Application "Internal RTC"
Product manual 2CKA00xx73xxxxx
│
268
Name Object function Length Data type Flags
K L S U
A
Block Input 1 bit
[1.002]
Boolean
K - S -
A
Fan switch
Step output
Input/
Output
1 byte
[5.100}
Fan speed level
(0 - 255)
K - S U
A
Status output steps Input 1 byte
[5.100}
Fan speed level
(0 - 255)
K - S -
A
Output 1
Input/
Output
1 bit
[1.002]
Boolean
K - S U
A
Output 2
Input/
Output
1 bit
[1.002]
Boolean
K - S U
A
Output 3
Input/
Output
1 bit
[1.002]
Boolean
K - S U
A
Output 4
Input/
Output
1 bit
[1.002]
Boolean
K - S U
A
Output 5
Input/
Output
1 bit
[1.002]
Boolean
K - S U
A
Output 6
Input/
Output
1 bit
[1.002]
Boolean
K - S U
A
Output 7
Input/
Output
1 bit
[1.002]
Boolean
K - S U
A
Output 8
Input/
Output
1 bit
[1.002]
Boolean
K - S U
A
Block Input 1 bit
[1.002]
Boolean
K - S -
A
Split Unit Control
Control On/Off
Input/
Output
1 bit
[1.001]
Switching
K - S U
A
Setpoint temp
Input/
Output
2 bytes
[9.001]
Temperature
(°C)
K - - U
-
Actual temperature Input 2 bytes
[9.001]
Temperature
(°C)
K - S U
A
Fan speed /
level
Input/
Output
1 byte
[5.010]
Counting pulses
(0 - 255)
K - S U
A
Operating mode
Input/
Output
1 byte
[20.102]
HVAC control
mode
K - S U
A
Horizontal oscillation
Input/
Output
1 bit
[1.001]
Switching
K - S U
A
Vertical oscillation
Input/
Output
1 bit
[1.001]
Switching
K - S U
A
Silent mode
Input/
Output
1 bit
[1.001]
Switching
K - S U
A
Boost Input 1 bit
[1.001]
Switching
K - S U
A
Forced operation Input 1 bit
[1.001]
Switching
K - S -
A

