ABB SmartTouch i-bus KNX User Manual

Communication objects
Application "Internal RTC"
Product manual 2CKA00xx73xxxxx
│
269
Name Object function Length Data type Flags
K L S U A
Window contact Input 1 bit
[1.001]
Switching
K - S - A
Presence Input 1 bit
[1.001]
Switching
K - S - A
Block Input 1 bit
[1.002]
Boolean
K - S - A
VRV control
Value 1 [send]
Input/
Output
1 bit
[1.001]
Switching
K - - U -
Value 2 [send] Output 1 byte
[5.010]
Counting pulses
(0 - 255)
K - - U -
Status value [receive] Input 1 byte
[5.010]
Counting pulses
(0 - 255)
K - - U -
Block Output 2 bytes
[9.001]
Temperature
(°C)
K - S - A
Status value Input 1 bit
[1.001]
Switching
K - S - A
Block Input 1 byte
[5.010]
Counting pulses
(0 - 255)
K - S U A
Value blue
Input/
Output
1 byte
[5.010]
Counting pulses
(0 - 255)
K - S U A
Value RGB [3 bytes] Input 2 bytes
[9.001]
Temperature
(°C)
K - S - A
Room temperature display (from
VRV)
Input 2 bytes
[9.001]
Temperature
(°C)
K - S - A
Value white Input 1 byte
[5.010]
Counting pulses
(0 - 255)
K - S - A
Temperature sensor fault Input 1 bit
[1.002]
Boolean
K - S - A
Block Input 1 bit
[1.002]
Boolean
K - S - A
Scene
Scene number 1 Output 1 byte
[18.001]
Scene control
K - - U -
Scene number 2 Output 1 byte
[18.001]
Scene control
K - - U -
Scene number 3 Output 1 byte
[18.001]
Scene control
K - - U -
Scene number 4 Output 1 byte
[18.001]
Scene control
K - - U -

