ABB SmartTouch i-bus KNX User Manual

Communication objects
Application "Internal RTC"
Product manual 2CKA00xx73xxxxx
│
270
Name Object function Length Data type
Flags
K L S U A
Scene number 6 Output 1 byte
[18.001]
Scene control
K - - U -
Scene number 7 Output 1 byte
[18.001]
Scene control
K - - U -
Scene number 8 Output 1 byte
[18.001]
Scene control
K - - U -
Scene number 9 Output 1 byte
[18.001]
Scene control
K - - U -
Scene number 10 Output 1 byte
[18.001]
Scene control
K - - U -
Scene number status Input 1 byte
[18.001]
Scene control
K - S - A
Block Input 1 bit
[1.002]
Boolean
K - S - A
Slider value
Value [1 byte] unsigned
Input/
Output
1 byte
[5.001]
Percent
(0 - 100%)
K - S U A
Status [1 byte] unsigned Input 1 byte
[5.001]
Percent
(0 - 100%)
K - S - A
Value [1 byte] unsigned
Input/
Output
1 byte
[5.010]
Counting pulses
(0 - 255)
K - S U A
Status [1 byte] unsigned Input 1 byte
[5.010]
Counting pulses
(0 - 255)
K - S - A
Value [1 byte] signed)
Input/
Output
1 byte
[6.010]
Counting pulses
(-128 - 127)
K - S U A
Status [1 byte] signed Input 1 byte
[6.010]
Counting pulses
(-128 - 127)
K - S - A
Value [2 byte] unsigned
Input/
Output
2 byte
[7.001]
Counting pulses
K - S U A
Status [2 byte] unsigned Input 2 byte
[7.001]
Counting pulses
K - S - A
Value [2 byte] signed)
Input/
Output
2 byte
[8.001]
Pulse difference
K - S U A
Status [2 byte] signed Input 2 byte
[8.001]
Pulse difference
K - S - A
Value [2 Byte] float
Input/
Output
2 byte
[9.001]
Temperature
(°C)
K - S U A
Status [2 byte] float Input 2 byte
[9.001]
Temperature
(°C)
K - S - A

