See also
Quick Start ATP Configuration for EN50136 ATS below
Configuring Event Profiles on page233
Event Exception Definition on page233
Configuring Command Profiles on page235
FlexC Status on page136
Configuring an EN50136-1 ATS or Custom ATS on page218
15.11.2.1 Operation Mode
The system uses the store-and-forward method when communicating events.
The SPC Alarm System sends events to SPC Com XT and requires an acknowledgment from SPC
Com XT before the SPC Alarm System considers the event to have been successfully transmitted.
SPC Com XT only acknowledges the event after it has successfully written the event to the SQL
database. SPC Com XT then forwards the event to the SPC Com XT Client and Sur-Gard interfaces.
15.11.2.2 Quick Start ATP Configuration for EN50136 ATS
FlexC provides the following out of the box features that enable you to get FlexC up and running
quickly:
l
Quick start configuration page for an EN50136 Single Path ATS, Dual Path ATS and Dual
Path Dual Server ATS
