R3132 Series Spectrum Analyzer Operation Manual
3.3.18 POWER MEASURE Key (Power Measurement)
3-65
ON: Allows you to set the sweep count. A pass/fail judgment
is performed when the number of sweeps matches the
specified sweep count.
NOTE: If Trace mode is set to Write mode, it is automatically
changed as shown below according to the Detector setting
as shown below:
The Trace mode stays in Write mode if Detector mode is
set to Normal.
The Trace mode is changed to Max Hold mode if Detector
mode is set to Positive.
The Trace mode is changed to Min Hold mode if Detector
mode is set to Negative.
The Average Power measurement is started if Detector
mode is set to Sample.
OFF: Turns the sweep count off. The Max Hold mode, Min
Hold mode, Average function, Power Average function
or Average Power measurement is turned off and a
pass/fail judgment is performed for each sweep.
PASS Judge UP/LOW Toggles the pass area between UP and LOW.
UP: The area above the limit level is set to Pass.
LOW: The area below the limit level is set to Pass.
Spurious Time OFF Turns the spurious measurement (zero span mode) off, and dis-
plays the Power menu.
Single Measure ON/OFF Sets the sweep conditions used in Single Sweep Mode.
ON: Pressing the
SINGLE
key performs the sweep the spec-
ified number of measurement times when the channel
power, total power, or average power is measured while
the average or power average function is turned on.
Note that the average and power average functions re-
quire the OBW, ACP (FULL, CARRIER), and spec-
trum mask measurement functions.
OFF: Pressing the SINGLE key performs the sweep only
once.
2/2_more Displays the Power menu (1/2).
