R3132 Series Spectrum Analyzer Operation Manual
4.2.3 GPIB Interface Functions
4-10
(2) Setting the GPIB Address
The GPIB Address dialog box is displayed.
1. Press
CONFIG
and GPIB.
The GPIB Address dialog box is displayed.
2. Use the data knob, the step keys, or the numeric keys to set the GPIB address as
required.
3. Press
ENTER (Hz)
to set the address.
(3) Turning the display off
If the screen display is turned off, the speed of measurements made using GPIB control increases.
1. Press
CONFIG
and Annotation ON/OFF (OFF).
OFF is selected, and all indications except for the trace are removed.
4.2.3 GPIB Interface Functions
Code Description
SH1 Source handshake
AH1 Acceptor handshake
T6 Basic talker, serial polling, listener-specified talker cancel
TE0 Extended talker (not available)
L4 Basic listener function, talker-specified listener cancel
LE0 Extended listener (not available)
SR1 Service request function
RL1 Remote, local, local lockout
PP0 Parallel polling (not available)
DC1 Device clear
DT0 Device trigger (not available)
C0 System controller (not available)
E1 Using open-collector bus driver
