ADVANTEST R3132 Series

R3132 Series Spectrum Analyzer Operation Manual
7.2 R3132N Specifications
7-5
7.2 R3132N Specifications
(1) Frequency
Characteristics Specification
Frequency range 9 kHz to 3.0 GHz
Frequency readout accuracy
(Start, Stop, CF, Marker)
± (Frequency readout × freq. reference accuracy + SPAN × 1%
+ RBW × 15% + 60 Hz)
Count frequency marker
Resolution
Count Accuracy
1 Hz to 1 kHz
± (Marker frequency × freq. reference accuracy + 1LSD)
(S/N ≥ 25dB, SPAN ≤ 200MHz)
Frequency reference
Aging
Temperature stability
±2 × 10
-6
/year
±1 × 10
-5
(from 0°C to 50°C)
Frequency span
Range
Accuracy
1 kHz to 3 GHz and 0 Hz (zero span)
±1% of Span
Residual FM
Zero Span ≤ 60Hz p-p/100ms
Noise Sidebands freq. ≤ 2.6GHz
≤ -100 dBc/Hz at 10 kHz offset
(RBW 300 Hz OPT27)
≤ -105 dBc/Hz at 20 kHz offset
freq. > 2.6GHz
≤ -98 dBc/Hz at 10 kHz offset
(RBW 300 Hz OPT27)
≤ -103 dBc/Hz at 20 kHz offset
Resolution Bandwidth
At 3 dB: Range
RBW Accuracy
Selectivity
(60 dB : 3 dB)
QP (at 6 dB) Range:
1 kHz to 3 MHz 1-3-10 sequence
±20% from 1 kHz to 1 MHz
±25% for 3 MHz
< 15 : 1
1 MHz, 120 kHz, 9 kHz
Video Bandwidth 10 Hz to 3 MHz (1-3-10 sequence)
