ADVANTEST R3132 Series

R3132 Series Spectrum Analyzer Operation Manual
7.2 R3132N Specifications
7-6
(2) Amplitude Range
(3) Sweep
Characteristics Specification
Measurement range +134 dBµV to displayed Average Noise Level
Maximum input level
Preamplifier OFF
Preamplifier ON
(Input attenuator ≥ 10 dB)
+134 dBµV
±50 VDC max.
+120 dBµV
±50 VDC max.
Display range
Log
Linear
10 × 10 div
10, 5, 2, 1 dB/div
10% of reference level/div
Reference level range
Preamplifier OFF
Log
Linear
Preamplifier ON
Log
Linear
(Input attenuator 0 to 50 dB)
+44.8 dBµV to +148.8 dBµV (0.1 dB step)
172.8 µV to +27.39 V
(Input attenuator 0 to 30 dB)
+26.8 dBµV to +118.8 dBµV (0.1 dB step)
21.75 µV to 866 mV
Input attenuator range 0 to 50 dB (5 dB step)
Characteristics Specification
Sweep time 20ms to 1000s
Sweep time Accuracy ±2%
Trigger mode FREE RUN, LINE, VIDEO, EXT, TV
Sweep Mode REPEAT, SINGLE
