ADVANTEST R3132 Series

R3132 Series Spectrum Analyzer Operation Manual
7.3 R3162 Specifications
7-10
(2) Amplitude Range
(3) Sweep
Characteristics Specification
Measurement range +30 dBm to displayed Average Noise Level
Maximum input level
Preamplifier OFF
Preamplifier ON
(Input attenuator ≥ 10 dB)
+30 dBm
0 VDC max.
+13 dBm
0 VDC max.
Display range
Log
Linear
10 × 10 div
10, 5, 2, 1 dB/div
10% of reference level/div
Reference level range
Preamplifier OFF
Log
Linear
Preamplifier ON
Log
Linear
(Input attenuator 0 to 75 dB)
-64 dBm to +65 dBm (0.1 dB step)
141.1 µV to 397.63 V
(Input attenuator 0 to 30 dB)
-82 dBm to +10 dBm (0.1 dB step)
17.76 µV to 707.1 mV
Input attenuator range 0 to 75 dB (5 dB step)
Characteristics Specification
Sweep time 20ms to 1000s
Sweep time Accuracy ±2%
Trigger mode FREE RUN, LINE, VIDEO, EXT, TV
Sweep Mode REPEAT, SINGLE
