ADVANTEST R3132 Series

R3132 Series Spectrum Analyzer Operation Manual
7.3 R3162 Specifications
7-11
(4) Dynamic Range
*1 For a temperature range of 20°C to 30°C. Add 2 dB for a temperature range of 0°C to 50°C.
Characteristics Specification
Displayed Average Noise Level
Preamplifier OFF
Preamplifier ON
with RBW 1 kHz, VBW 10 Hz and input attenuator 0 dB, f ≥ 10 MHz
band 0: -117 dBm + 2f (GHz)dB *1
band 1-: -115 dBm + 0.5f (GHz)dB *1
band 1+: -115 dBm + 0.5f (GHz)dB *1
-132 dBm + 3f (GHz)dB
Freq. Range 1 MHz to 3.3 GHz
Gain compression (1 dB)
Preamplifier OFF
Preamplifier ON
frequency ≥ 200 MHz
> 0 dBm (mixer input level)
> -25 dBm (RF input level)
Spurious Response
Second harmonic distortion
Third order intermodulation
distortion
Image/Multiple/Out-of-band
response
Preamplifier OFF
≤ -80 dBc
(Mixer input level -30 dBm, 2-signal difference > 50 kHz
f ≥ 200 MHz)
< -70 dBc up to 8 GHz
Residual responses (input terninated 50Ω, input attenuator 0 dB)
Freq. range Mixer level Distortion level
100 MHz to 800 MHz -30 dBm ≤ -70 dBc
≥ 800 MHz (band 0) -30 dBm ≤ -80 dBc
≥ 3.3 GHz -10 dBm ≤ -100 dBc
band 0 band 1-, 1+
Preamplifier OFF ≤ -100 dBm ≤ -90 dBm
Preamplifier ON ≤ -105 dBm not applicable
