ADVANTEST R3132 Series User Manual

R3132 Series Spectrum Analyzer Operation Manual
7.6 Options
7-27
(2) R3132/62
• OPT74 Tracking Generator
Characteristics Specification
Frequency range 100kHz to 3.0GHz
Output level range 0 to -59.9dBm
Output level accuracy ±0.5 dB
(30 MHz, -10 dBm, 20°C to 30°C)
Output flatness ±1.0dB (100kHz to 1GHz)
±1.5dB (100kHz to 3GHz)
(The reference signal level and frequency are -10dBm and
30 MHz, respectively.)
Output level switching uncertainty ±1.0dB (100kHz to 1GHz)
(Output level ≥ -30dBm)
±2.0dB (100kHz to 2.6GHz)
±3.0dB (100kHz to 3GHz)
(The reference level is -10dBm.)
Spurious output
Harmonics spurious signals
Non-harmonics spurious signals
≤ -20dBc (Output level = -10dBm)
≤ -30dBc (Output level = -10dBm)
TG leakage ≤ -100dBm (Input ATT = 0dB)
Output Impedance
VSWR
50Ω (nominal)
≤ 2 (For the output level of -10dBm or less)
(characteristic value)
Maximum allowable input level +15dBm
±10V
Mass 1 kg or less
