R3132 Series Spectrum Analyzer Operation Manual
7.6 Options
7-28
(3) R3132N
• OPT74 Tracking Generator
(4) R3172
• OPT03 Ext. Mixer local Out
Characteristics Specification
Frequency range 100kHz to 3.0GHz
Output level range 105 to -45.1dBµV
Output level accuracy ±0.5dB
(30MHz, 95dBµV, 20°C to 30°C)
Output flatness ±1.0dB (100kHz to 1GHz)
±1.5dB (100kHz to 2.2GHz)
(The reference signal level and frequency are 95dBµV and
30MHz, respectively.)
Output level switching uncertainty ±1.0dB (100kHz to 1GHz)
(Output level ≥ -75dBµV)
±2.0dB (100kHz to 2.2GHz)
(The reference level is 95dBµV.)
Spurious output
Harmonics spurious signals
Non-harmonics spurious signals
≤ -20dBc (Output level = 95dBµV)
≤ -30dBc (Output level = 95dBµV)
TG leakage ≤ 7dBµV (Input ATT = 0dB)
Output Impedance
VSWR
75Ω (nominal)
(for the output level of 95dBµV or less)
≤ 2 (100kHz to 2.2GHz) (characteristic value)
Maximum allowable input level 123dBµV
±10V
Mass 1 kg or less
Characteristics Specification
Frequency range 4.0 GHz to 7.6 GHz
Output level > +8dBm
Output impedance 50Ω (nominal)
Connector SMA female
