ADVANTEST R3132 Series User Manual

R3132 Series Spectrum Analyzer Operation Manual
7.6 Options
7-29
(5) R3172/82
Characteristics
Specification
OPT16 OPT17 OPT18 OPT19
Frequency range 26.5 to 40 GHz 40 to 60 GHz 50 to 75 GHz 75 to 85 GHz
70 to 80 GHz 85 to 110 GHz
Waveguide WR-28 WR-19 WR-15 WR-10
Harmonic order N 6- 8- 10- 16-
12-
Maximum input level [dBm] 20 20 20 20
Frequency response [dB] ±5 ±5 ±5 ±5
One-dB gain compression [dBm] -1 -1 -6 -6
Displayed average noise level [dBm]
(RBW1 kHz, VBW10 Hz)
-99 -93 -90 -85
-88 -80
