Table 1. Safety Decal Details
To prevent death or serious injury:
• DO NOT step on or touch moving conveyor belt.
• Shut off and lock out power to adjust, service, or
clean.
OPEN BELT CONVEYOR
WARNING
P1513045
To prevent serious injury or death:
• Read and understand the manual before
assembling, operating, or maintaining the
equipment.
• Only trained personnel may assemble, operate,
or maintain the equipment.
• Children and untrained personnel must be kept
outside of the work area.
• Do not modify the equipment. Keep in good
working order.
• If the manual, guards, or decals are missing or
damaged, contact factory or representative for
free replacements.
• Lock out power before performing maintenance.
• To prevent equipment collapse or upending,
support equipment tube while disassembling
certain components.
• Follow grain storage structure manufacturer's
warnings when loading and unloading.
• Electric motors must be grounded. Disconnect
power before resetting overloads.
WARNING
P1513001
To prevent death or serious injury:
• When operating or moving, keep equipment
away from overhead power lines and devices.
• Fully lower equipment before moving.
This equipment is not insulated.
Electrocution can occur without direct contact.
DANGER
ELECTROCUTION HAZARD
P1513003
To prevent damage, wheels must be
free to move when raising or lowering
equipment.
When equipment is positioned, chock
all wheels.
NOTICE
P1513052
To prevent serious injury or death:
• Securely attach equipment to vehicle with
correct pin and safety chains.
• Use a tow vehicle to move equipment.
TRANSPORT HAZARD
WARNING
P1513037
TAKE-UP ROLLER
X
NUT
PIPE
To prevent belt damage, the conveyor belt must be tensioned
correctly and the take-up roller must be straight.
DO NOT adjust belt tracking with the take-up roller.
To tension the belt correctly:
1. While the conveyor is running empty, adjust the nut on both
sides of the s-drive so that the edge of the pipe is within the
green area.
2. Keep the take-up roller straight by adjusting the nut so that the
distance (X) is the same on both sides of s-drive.
See manual for further information and belt tracking instructions.
NOTICE
8110-00225
8110-00227 8110-00226
1. SAFETY FIELD LOADER S-DRIVE – PORTABLE GRAIN BELT CONVEYOR
