68 8210-00020 R1

Install the Sides (x2)

Item

Description

Side Frame

1/2" X 2-1/2" Hex Bolt (GR 8)

1/2" Lock Nut

Hardware Kit: HRDW-15–102

3. ASSEMBLY FIELD LOADER S-DRIVE – PORTABLE GRAIN BELT CONVEYOR
