8210-00020 R1 69

Install the Bottom

Item

Description

1/2" X 1" Hex Bolt (GR 8)

2 Bottom Frame

1/2" Locknut

Hardware Kit: HRDW-15–131

Note

Leftover hardware from this bag is used to install the crossbrace and fuel tank mount.

FIELD LOADER S-DRIVE – PORTABLE GRAIN BELT CONVEYOR 3. ASSEMBLY
