8210-00020 R1 79

Item

Description

Crossbrace

1/2" X 1" Hex Bolt (GR 8)

Motor Guard

1/2" Flange Nut

Hardware Kit: HRDW-15–131

FIELD LOADER S-DRIVE – PORTABLE GRAIN BELT CONVEYOR 3. ASSEMBLY
