2D-LC User Guide 81
4Installation
Hardware Installation
The
1
D/
2
D switching valve offers the possibility to exclude the
2
D flow path of the
instrument to run both
1
D and
2
D experiments which is useful for example if one
mass spectrometer is used for both
1
D and
2
D experiments. Two basic setups
are supported (setup E and F). The recommended setups for a
1
D/
2
D Switching
valves do not support the use of ICC column compartments, column switching
valves or the use of separate
1
D and
2
D MCTs/TCCs! To run 1D experiments, the
2
D mode must be disabled. This must be done in the UI of the 2D-LC Method
Editor, see “Off” on page 128.
Number of
Capillary
# Connection L x ID [mm] P/N Description
D1 1
Capillary from
2
D detector to T-piece
0.12 x 400 5067-4606 Capillary ST 400x0.12 S/SH
D2 1 T-piece 0100-0969 1/16in Tee, SST, Low Dead
Volume
D3 1 Capillary from MS to T-piece (self cut) 0.12 x 400 0890-1915 Capillary PEEK, 0.12x1250
D4 2 T-piece to pressure relief valve;
pressure relief valve to diverter valve
0.3 x 80 5500-1228 Capillary ST 0.3x80 SL/SL
D5 1 Pressure relief valve G4212-60022 Pressure relief valve
D6 1 blank nut 01080-83202 Blanking Nut 1/16 in SST
D7 1 diverter valve to waste 5062-2462 Tubing PTFE 0.7 mm x 5m
D8 1 peak fittings 5063-6591 Fitting-Fingertight PEEK for
1/16-in
D9 1 Valve holder for Valve drive to attach to
MCT
5067-6138 Valve Holder Kit Right-IF-II-G
D10 1 Diverter Valve G4231A
G4231C
G4232A
G4232C
2pos/6port, 800bar
2pos/6port, 1300bar
2pos/10port, 800bar
2pos/10port, 1300bar
For all other capillaries / connections, please refer to Figure 31 on page 73, Figure 32 on page 74, and Figure 33 on page 75.
