Agilent Technologies InfiniiVision 3000 X-Series User Manual

Waveform Generator 17
Agilent InfiniiVision 3000 X-Series Oscilloscopes User's Guide 261
Sine Use the Frequency/Frequency
Fine/Period/Period Fine, Amplitude/High-Level,
and Offset/Low-Level softkeys to set the sine
signal parameters.
100 mHz to
20 MHz
20 mVpp to
5Vpp
±2.50 V
Square Use the Frequency/Frequency
Fine/Period/Period Fine, Amplitude/High-Level,
Offset/Low-Level, and Duty Cycle softkeys to set
the square wave signal parameters.
The duty cycle can be adjusted from 20% to 80%.
100 mHz to
10 MHz
20 mVpp to
5Vpp
±2.50 V
Ramp Use the Frequency/Frequency
Fine/Period/Period Fine, Amplitude/High-Level,
Offset/Low-Level, and Symmetry softkeys to set
the ramp signal parameters.
Symmetry represents the amount of time per cycle
that the ramp waveform is rising and can be
adjusted from 0% to 100%.
100 mHz to
200 kHz
20 mVpp to
5Vpp
±2.50 V
Pulse Use the Frequency/Frequency
Fine/Period/Period Fine, Amplitude/High-Level,
Offset/Low-Level, and Width/Width Fine
softkeys to set the pulse signal parameters.
The pulse width can be adjusted from 20 ns to the
period minus 20 ns.
100 mHz to
10 MHz.
20 mVpp to
5Vpp
±2.50 V
DC Use the Offset softkey to set the DC level. n/a n/a ±2.50 V
Noise Use the Amplitude/High-Level and
Offset/Low-Level to set the noise signal
parameters.
n/a 20 mVpp to
5Vpp
±2.50 V
Sine Cardinal Use the Frequency/Frequency
Fine/Period/Period Fine, Amplitude, and Offset
softkeys to set the sinc signal parameters.
100 mHz to
1MHz
20 mVpp to
5Vpp
±1.25 V
Exponential
Rise
Use the Frequency/Frequency
Fine/Period/Period Fine, Amplitude/High-Level,
and Offset/Low-Level softkeys to set the
exponential rise signal parameters.
100 mHz to
5MHz
20 mVpp to
5Vpp
±2.50 V
Waveform
Ty pe
Characteristics Frequency
Range
Max.
Amplitude
(High-Z)
1
Offset
(High-Z)
1
