Math Waveforms 4

Agilent InfiniiVision 3000 X-Series Oscilloscopes User's Guide 75

To perform transforms or filters on an arithmetic operation

To perform a transform function (see "Math Transforms" on page 78) or

filter (see "Math Filters" on page 94) on the add, subtract, or multiply

arithmetic operations:

1 Press the Function softkey and select g(t): Internal.

2 Use the Operator, Source 1, and Source 2 softkeys to set up an arithmetic

operation.

3 Press the Function softkey and select f(t): Displayed.

4 Use the Operator softkey to select a transform function or filter.

5 Press the Source 1 softkey and select g(t) as the source. Note that g(t) is

only available when you select a transform function in the previous

step.

To adjust the math waveform scale and offset

1 Make sure the multiplexed scale and position knobs to the right of the

[Math] key are selected for the math waveform.

If the arrow to the left of the [Math] key is not illuminated, press the

key.

2 Use the multiplexed scale and position knobs just to the right of the

[Math] key to re-size and re- position the math waveform.

See Also • "Units for Math Waveforms" on page 76

NOTE

Math Scale and Offset are Set Automatically

Any time the currently displayed math function definition is changed, the function is

automatically scaled for optimum vertical scale and offset. If you manually set scale and

offset for a function, select a new function, then select the original function, the original

function will be automatically rescaled.
