215
Agilent InfiniiVision 3000 X-Series Oscilloscopes
User's Guide
s1
14
Measurements
To make automatic measurements 216
Measurements Summary 217
Voltage Measurements 221
Time Measurements 228
Count Measurements 235
Mixed Measurements 236
Measurement Thresholds 237
Measurement Window with Zoom Display 239
Measurement Statistics 239
The [Meas] key lets you make automatic measurements on waveforms.
Some measurements can only be made on analog input channels.
The results of the last four selected measurements are displayed in the
Measurements information area on the right-hand side of the screen.
Cursors are turned on to show the portion of the waveform being
measured for the most recently selected measurement (bottom- most on the
right- side measurement area).
Post Acquisition Processing
In addition to changing display parameters after the acquisition, you can perform all of the
measurements and math functions after the acquisition. Measurements and math
functions will be recalculated as you pan and zoom and turn channels on and off. As you
zoom in and out on a signal using the horizontal scale knob and vertical volts/division knob,
you affect the resolution of the display. Because measurements and math functions are
performed on displayed data, you affect the resolution of functions and measurements.
