22 Reference
Differential Probes
The following differential probes can be used with the InfiniiVision
3000 X-Series oscilloscopes.
Table 6 Active Probes
Model Description Quantity
Supported
1
1130A 1.5 GHz InfiniiMax amplifier, requires one or more
InfiniiMax probe heads: E2675A, E2668A, E2669A
2
1131A InfiniiMax 3.5 GHz probe 2
1132A InfiniiMax 5 GHz probe 2
1134A InfiniiMax 7 GHz probe 2
1156A Active probe, 1.5 GHz 4
1157A Active probe, 2.5 GHz 4
1158A Active probe, 4 GHz 4
N2744A T2A probe interface adapter Unknown,
depends on
probes
connected
N2795A Active probe, 1 GHz with AutoProbe interface 2
N2796A Active probe, 2 GHz with AutoProbe interface 2
1
See "AutoProbe Interface" on page 334.
Table 7 Differential Probes
Model Description Quantity
Supported
1
1141A Active differential probe, 200 MHz, 200 VDC + peak AC max (requires
1142A power supply)
1144A Active probe, 800 MHz (requires 1142A power supply)
1145A Active probe, 750 MHz 2-ch (requires 1142A power supply)
