Horizontal Controls 2
Agilent InfiniiVision 3000 X-Series Oscilloscopes User's Guide 61
• Captured data (see "To navigate time" on page 61).
• Search events (see "To navigate search events" on page 61).
• Segments, when segmented memory acquisitions are turned on (see "To
navigate segments" on page 62).
To navigate time
When acquisitions are stopped, you can use the navigation controls to play
through the captured data.
1 Press [Navigate].
2 In the Navigate Menu, press Navigate; then, select Time.
3 Press the navigation keys to play backward, stop, or play
forward in time. You can press the or keys multiple times to
speed up the playback. There are three speed levels.
To navigate search events
When acquisitions are stopped, you can use the navigation controls to go
to found search events (set using the [Search] key and menu, see
"Searching for Events" on page 59).
1 Press [Navigate].
2 In the Navigate Menu, press Navigate; then, select Search.
3 Press the back and forward keys to go to the previous or next
search event.
When searching Serial decode:
• You can press the stop key to set or clear a mark.
• The Auto zoom softkey specifies whether the waveform display is
automatically zoomed to fit the marked row as you navigate.
• Pressing the Scroll Lister softkey lets you use the Entry knob to scroll
through data rows in the Lister display.
