Agilent Technologies InfiniiVision 3000 X-Series User Manual

Measurements 14
Agilent InfiniiVision 3000 X-Series Oscilloscopes User's Guide 221
You can also configure the [Quick Action] key to display the Snapshot All
popup. See "Configuring the [Quick Action] Key" on page 311.
Voltage Measurements
The following figure shows the voltage measurement points.
Measurement units for each input channel can be set to Volts or Amps
using the channel Probe Units softkey. See "To specify the channel units" on
page 69.
The units of math waveforms are described in "Units for Math
Waveforms" on page 76.
• "Peak-Peak" on page 222
Amplitude
Maximum
Minimum
Base
Top
Peak-Peak
