Access the Built-In Quick Help
To view Quick
Help
1 Press and hold the key or softkey for which you would like to view
help.
Status line The top line of the display contains vertical, horizontal, and trigger setup
information.
Display area The display area contains the waveform acquisitions, channel identifiers, and
analog trigger, and ground level indicators. Each analog channel's information
appears in a different color.
Signal detail is displayed using 256 levels of intensity. For more information
about viewing signal detail see “To adjust waveform intensity" on page 131.
For more information about display modes see Chapter 8, “Display Settings,”
starting on page 131.
Information area The information area normally contains acquisition, analog channel,
automatic measurement, and cursor results.
Menu line This line normally contains menu name or other information associated with
the selected menu.
Softkey labels These labels describe softkey functions. Typically, softkeys let you set up
additional parameters for the selected mode or menu.
Pressing the Back/Up key at the top of the menu hierarchy turns off
softkey labels and displays additional status information describing channel
offset and other configuration parameters.
