Alcatel-Lucent 7750 SR OS - Page 1201

Virtual Private Routed Network Services
7750 SR OS Services Guide Page 1201
Sample Output
*A:ALA-12# show router 3 static-route
==============================================================================
Route Table
==============================================================================
IP Addr/mask Pref Metric Type Nexthop Interface Active
------------------------------------------------------------------------------
192.168.250.0/24 5 1 ID 10.200.10.1 to-ser1 Y
192.168.252.0/24 5 1 NH 10.10.0.254 n/a N
192.168.253.0/24 5 1 NH to-ser1 n/a N
192.168.253.0/24 5 1 NH 10.10.0.254 n/a N
192.168.254.0/24 4 1 BH black-hole n/a Y
==============================================================================
*A:ALA-12#
*A:ALA-12# show router 3 static-route 192.168.250.0/24
==============================================================================
Route Table
==============================================================================
IP Addr/mask Pref Metric Type Nexthop Interface Active
------------------------------------------------------------------------------
192.168.250.0/24 5 1 ID 10.200.10.1 to-ser1 Y
==============================================================================
*A:ALA-12#
*A:ALA-12# show router 3 static-route preference 4
=============================================================================
Route Table
==============================================================================
Type
BH — The static route is a black hole route. The Nexthop for this
type of route is
black-hole.
ID — The static route is an indirect route, where the
nexthop for
this type of route is the non-directly connected next hop.
NH — The route is a static route with a directly connected next hop.
The
Nexthop for this type of route is either the next hop IP address
or an egress IP interface name.
Next Hop
The next hop for the static route destination.
Protocol
The protocol through which the route was learned.
Interface
The egress IP interface name for the static route.
n/a — indicates there is no current egress interface because the
static route is inactive or a black hole route.
Active
N — The static route is inactive; for example, the static route is
disabled or the next hop IP interface is down.
Y — The static route is active.
No. of Routes:
The number of routes displayed in the list.
Label Description (Continued)
