Amazone Condor 12001-C User Manual

Coupling and uncoupling the implement
Condor 12001-C/15001-C BAH0030-4 07.15
105
7. Lower the jack using the cable pull and peg
the position with the pin.
8. Lock the pin by turning (see Fig. 106).
Fig. 108
9. Remove the wheel chocks from the
transport bracket(s).
Fig. 109
10. Secure the implement wheels with two
wheel chocks (Fig. 110/1).
11. Uncouple the supply line and the brake line
from the tractor (see section "Uncoupling
the supply and brake line", Seite 56).
Fig. 110
When uncoupling the pneumatic brake lines first of all disconnect the
red hose coupling (supply line) and then the yellow hose coupling
(brake line) from the tractor!
