Coupling and uncoupling the implement
Condor 12001-C/15001-C BAH0030-4 07.15
95
WARNING
Risk of contusions, cutting, catching, drawing in and knocks
when the implement unexpectedly releases from the tractor!
Use the intended equipment to connect the tractor and the
implement in the proper way.
When coupling the implement to the tractor's three-point
hydraulic system, it is vital to ensure that the tractor mount
categories of the tractor and the implement are the same.
WARNING
Risk of energy supply failure between the tractor and the
implement through damaged power lines!
During coupling, check the course of the power lines. The supply
lines
Must give slightly without tension, bending or rubbing on all
movements of the connected implement.
must not chafe against other parts.
DANGER
If the tractor has been separated from the implement, always
secure the implement with the service parking brake and
also with 2 wheel chocks.
secure the implement with 2 wheel chocks if it has no brake
system!
DANGER
The lower link of the tractor must not have any lateral play so
that the implement always runs centrically behind the tractor and
does not knock back and forth!
CAUTION
Only establish the implement connections once the tractor and
implement have been coupled, the tractor engine is shut down,
the tractor parking brake is applied and the ignition key is
removed!
Do not connect the supply line (red) of the service brake to the
tractor until the tractor engine is shut down, the tractor parking
brake is applied and the ignition key is removed!
