Coupling and uncoupling the implement
96
Condor 12001-C/15001-C BAH0030-4 07.15
The implements can be coupled or uncoupled when folded or
unfolded.
WARNING
Do not remove the wheel chocks until the implement is
connected to the tractor's lower links and the tractor parking
brake is applied.
CAUTION
Danger of getting crushed in the area of the moving draw rail.
1. Verify that the implement is secured with
wheel chocks (Fig. 96/1).
Fig. 96
2. Attach one ball sleeve (Fig. 97/1) with a
collecting tray over each of the lower links
of the drawbar and lock with a linch pin.
The ball sleeves depend on the tractor type
(see tractor operating manual).
Fig. 97
