21. Install the shot channel with the spring cotter pin
1
.
22. Couple the ISOBUS line.
23. Restart the implement.
CMS-I-00003814
6.4.11.4 Adjusting the scraper mechanically
NOTE
The adjustment of the scraper must be adapted to
the respective operating conditions. The optimum
adjustment can only be determined during field
operation.
1. If the control terminal detects doubles,
increase the setting value on the scraper
1
.
2. If the control terminal detects gaps,
reduce the setting value on the scraper
1
.
3. Check the adjustment of the scraper on the field
after driving a short distance.
1
CMS-I-00001918
6.4.11.5 Adjusting the scraper electrically
NOTE
The adjustment of the scraper must be adapted to
the respective operating conditions. The optimum
adjustment can only be determined during field
operation.
CMS-T-00001896-C.1
CMS-T-00001897-C.1
6 | Preparing the machine
Preparing the implement for operation
MG6660-EN-II | D.1 | 27.09.2021
100
