The determined gear ratio depends on the wheel slip.
3. To determine the pulses per 100 m during
operation,
refer to the AmaScan2 operating manual,
"Running in the pulses",
or
refer to the AmaCheck operating manual,
"Running in the pulses".
When the determined pulses per 100 m differs from
the values below, the desired grain spacing must be
calculated manually.
Gear wheel
I
Z
= Pulses per 100 m
Z=24 485
a
a
a
18,2
a
R
T
Z
E
R
R
I
I= ´
= ´ =
= ´ =
485
463 17 4,
CMS-I-00002683
a
R
= Manually calculated grain spacing
a
T
= Grain spacing determined on the control
terminal
I
Z
= 485 pulses per 100 m
I
E
= Determined pulses per 100 m
4. Manually calculate the desired grain spacing.
5. Read the gear ratio for the manually calculated
grain spacing from the table.
