Amazone Precea 3000 - Page 166

2. Remove the clamp
2
.
3. Remove the conveyor hose
1
from the fertiliser
coulter
3
.
4. To divert the conveyor air close to the ground,
fasten the conveyor hose on the implement with
the opening facing down.
CMS-I-00003920
5. Disconnect the air supply on the air distributor.
6. Seal the open connection with a cap
2
.
7. Install the clamp
1
.
CMS-I-00003918
6 | Preparing the machine
Preparing the implement for operation
MG6660-EN-II | D.1 | 27.09.2021
160
