8. To collect the residual quantity,
remove the singling disc
1
from the drive hub.
NOTE
When the collection bucket is hooked onto the
chute, the chute can be loaded with a maximum
of 12 kg.
9. When the residual quantity has been collected,
park the chute back into the hopper cover.
1
CMS-I-00001912
10. Position the singling disc
1
on the drive hub.
11. Turn the lock
1
beyond the notch
2
.
The points
3
are no longer aligned.
1
3
2
CMS-I-00001911
12. Close the cover
2
.
NOTE
Pay attention to the guide pin
1
.
13. Close the locks.
2
1
CMS-I-00001913
8 | Parking the machine
Emptying the seed hopper through the singling disc
MG6660-EN-II | D.1 | 27.09.2021
