2. Insert the unlocking tool
into the metering unit
cover
.
3. Unlock the metering unit cover on the metering
housing
.
4. Open the metering unit cover.
CMS-I-00002582
5. Turn the drive unit
counterclockwise.
6. Pull the drive unit out of the metering housing.
CMS-I-00002585
7. Take the roller cage
along with the metering
roller out of the metering housing.
CMS-I-00002584
6 | Preparing the machine
Preparing the implement for operation
MG6660-EN-II | D.1 | 27.09.2021
72
