LTE and TD-LTE Coverage Mapping 7-3 Coverage Mapping
3GPP MG PN: 10580-00234 Rev. T 7-7
Save the Coverage Mapping Information
1. Press the Measurements main menu key.
2. Press the Over-the-Air submenu key, then Mapping.
3. Coverage Mapping has three save options. Refer to “Save KML Points”, “Save Tab
Delimited Points” or “Save JPG”.
All files will be stored in the default save location. To change the default location:
1. Press Shift, then File (7) to access the File menu.
2. Press Save.
3. Press Change Save Location.
4. Select an existing folder or press the Create Folder submenu key to create a new folder
in the instrument’s internal memory or on a USB drive.
5. Press Set Location to make the selected folder the new default location for saving files.
Save KML Points
In the Coverage Mapping submenu, press Save/Recall Points/Map, then Save KML Points. In
the Save dialog, change the file name as appropriate, then press Enter. The following
information is saved for the points currently displayed on the screen:
• Location and time based on GPS information
• Cell, Group and Sector ID
• Center Frequency
• Measured signals: S-SS, RSRP, RSRQ and SINR
The .kml file can be recalled and viewed on the instrument. Refer to “Mapping Save/Recall
Menu” on page 7-13 for information on recalling a map.
The .kml file can also be opened and viewed using Google Earth and a network connection.
1. Connect your computer or mobile device to the instrument via the Web Remote Control
server. To do this, enter the instrument IP address in your Web browser address bar.
You can look up your instrument IP address by pressing Shift, then System (8),
followed by Status. If your instrument has not been set up with an IP address, press
System Options, then Ethernet Config to access the Ethernet Editor dialog.
Note
Installing Google Earth
If you don’t have Google Earth installed on your computer:
1. Go to www.google.com/earth
.
2. Click Download Google Earth and follow the on-screen instructions.
3. After installation and Google Earth is opened, user instructions and several
types of help are available from the Help pull-down menu.
