1 TRAKA - INTELLIGENT ACCESS MANAGEMENT

1.1 WELCOME

Welcome to Traka

This user guide has been prepared in order to assist you with every aspect of Traka ranging from planning to advanced

features of all the Traka systems.

The content of this guide is based upon the following software and firmware versions...

Software Version 02.42.0000

8bit Firmware Version 06.08.41 and below

16bit Firmware Version 04.00.12 and below
