2.3.7 L-SERIES
2.3.7.1 L-SERIES CABINET PREPARATION
Before attaching an L-Series Traka system to the wall you will need to remove various parts in order to access the
various fixing holes. Please refer to the anti static precautions before preparing the system.
NOTE: Any plastic protective film should be removed after installation in order to protect the stainless
steel finish and polycarbonate door.
1. Carefully unpack your Traka system and ensure all the necessary parts are there using the check list.
2. The L-Series system comes in two parts, the Pod and the Cabinet. Start with the cabinet(s) and install the
Pod last.
3. Using the Master Key open the door (if fitted) using the Door Release CAM Lock.
4. Using a 4mm Allen Key, remove the Cover Panel Screws one at a time and remove the cover panels.
