V3.5 14/08/19
UD0089
Page 37
This Document is uncontrolled unless over stamped "CONTROLLED DOCUMENT"
7. Using a 4mm Allen Key, replace the Cover Panels one at a time with the fixings removed earlier. Once the
cover panels have been replaced then close the door (if fitted).
8. Hook the Control Panel into the bottom of the Pod. Whilst holding the control panel, re-connect the following
wires to the Control PCB.
Earth Cable
Power Cable
Receptor Ribbon Cable
Reader Cable (Optional)
NOTE: For more details on the various PCB connections, please refer to the 8bit Control
PCB Diagrams or 16bit I/O PCB layout section of the Traka32 Help Guide.
9. Insert the Battery into the base of the Pod and connect to the Control PCB.
10. Switch the On/Off switch on the 8bit Control PCB or 16bit I/O PCB to On.
You should hear a double beep and the LCD should light up and start to display text. If this does not happen
then switch Off the On/Off switch and double check your connections.
11. Finally, close the Control Panel carefully and lock with the Master Key. The Control Panel should fit easily, if
not check that no wires have become caught or trapped between the Control Panel and the cabinet.
12. Now refer to the Commissioning section.
