8. Re-connect the Green & Yellow Earth cable connector.
9. Insert the Battery into the base of the Pod and connect to the 8bit Control PCB or 16bit I/O PCB.
10. Switch the On/Off switch on the 8bit Control PCB or 16bit I/O PCB to On.
You should hear a double beep and the LCD should light up and start to display text. The cabinet will continue
to beep whilst the door is open (if fitted). If this does not happen then switch Off the On/Off switch and
double check your connections.
11. Close the Control Panel Door.
12. The Control Panel is hooked in at the bottom and locked at the top. Using the Master Key, unlock the Control
Panel Lock.
13. Tilt the Control Panel forward and re-fit the plastic Wing Bolt.
14. Close and lock the Control Panel.
15. Close the door.
16. Now refer to the Commissioning section.
