9. Hook the Control Panel into the bottom of the Pod. Whilst holding the control panel, re-connect the following
wires to the Control PCB.
LCD
Keypad
Card Reader (optional)
Earth Cable
Receptor Cable
NOTE: For more details on the various PCB connections, please refer to the 8bit Control PCB Diagrams
or 16bit I/O PCB layout section of the Traka32 Help Guide.
10. Insert the Battery into the base of the Pod and connect to the 8bit Control PCB or 16bit I/O PCB respectively.
11. Switch the On/Off switch on the 8bit Control PCB or 16bit I/O PCB to On.
12. You should hear a double beep and the LCD should light up and start to display text. If this does not happen
then switch Off the On/Off switch and double check your connections.
13. Finally, close the Control Panel carefully into the Pod and lock with the Master Key.
14. The Control Panel should fit easily, if not check that no wires have become caught or trapped between the
Control Panel and the Pod.
15. Please now refer to the Commissioning section.
