Version 6.8 183 Mediant 2600 E-SBC
User's Manual 15. Services
3. Click Add; the following dialog box appears:
Figure 15-3: DHCP Option Table - Add Record Dialog Box
4. Configure additional DHCP Options for the DHCP server according to the parameters
described in the table below.
5. Click Submit.
Table 15-4: DHCP Option Table Parameter Descriptions
Parameter Description
Web: Index
CLI: dhcp option
[DhcpOption_Index]
Defines an index number for the new table record.
Note: Each table row must be configured with a unique index.
Web: DHCP Server Index
CLI: dhcp-server-number
[DhcpOption_DhcpServerIndex]
Associates the DHCP Option table entry with a DHCP server that
you configured in ''Configuring the DHCP Server'' on page 177.
Note: Currently, only one DHCP server (Index 0) can be
configured and therefore, this parameter is always set at 0.
Web: Option
CLI: option
[DhcpOption_Option]
Defines the code of the DHCP Option.
The valid value is 1 to 254. The default is 159.
For e
xample, for DHCP Option 150 (Cisco proprietary for defining
multiple TFTP server IP addresses), enter the value 150.
Web: Type
CLI: type
[DhcpOption_Type]
Defines the format (type) of the DHCP Option value that is
configured in the 'Value' parameter (see below).
[0] ASCII = (Default) Plain-text string (e.g., when the value is
a domain name).
[1] IP address = IPv4 address.
[2] Hexadecimal = Hexadecimal-encoded string.
For example, if you set the 'Value' parameter to "company.com",
you need to set the 'Type' parameter to ASCII.
