Version 6.8 191 Mediant 2600 E-SBC
User's Manual 15. Services
To configure a SIP Recording Routing rule:
1. Open the SIP Recording page (Configuration tab > VoIP menu > Services > SIP
Recording).
2. Click Add; the following dialog box appears:
Figure 15-6: SIP Recording Routing Table - Add Record
The figure above shows a configuration example where the device records calls made
by IP Group 1 to IP Group 2 that have the destination number prefix "1800". The
device records the calls from the leg interfacing with IP Group 2, sending the recorded
media to IP Group 3 (i.e., the SRS).
3. Configure a SIP recording route according to the parameters described in the table
below.
4. Click Submit, and then save ("burn") your settings to flash memory.
Table 15-6: SIP Recording Routing Parameter Descriptions
Parameter Description
Index
[SIPRecRouting_Index]
Defines an index number for the new table record.
Recorded IP Group ID
CLI: recorded-ip-group-id
[SIPRecRouting_RecordedIPGroupID]
Defines the IP Group participating in the call and
the recording is done
on the leg interfacing with this
IP Group.
Note: For an SBC RTP-SRTP session, the
recorded IP Group must be set to the RTP leg if
recording is required to be RTP, or set to the SRTP
leg if recording is required to be SRTP.
Recorded Source Prefix
CLI: recorded-src-prefix
[SIPRecRouting_RecordedSourcePrefix]
Defines calls to record based on source number or
URI.
Recorded Destination Prefix
CLI: recorded-dst-prefix
[SIPRecRouting_RecordedDestinationPrefix]
Defines calls to record based on destination
number or URI.
Peer IP Group ID
CLI: peer-ip-group-id
[SIPRecRouting_PeerIPGroupID]
Defines the peer IP Group that is participating in
the call.
