User's Manual 484 Document #: LTRT-42060
Mediant 2600 E-SBC
Parameter Description
Mode
Displays the Proxy Sets' operational mode:
"Parking" or "Homing": Redundancy mode, as configured by the
ProxySet_ProxyRedundancyMode parameter.
"Load Balancing: Proxy load balancing mode, as configured by
the ProxySet_ProxyRedundancyMode parameter.
For more information, see Configuring Proxy Sets.
Keep Alive
Displays whether the Proxy Keep-Alive feature is enabled ("Enabled")
or disabled ("Disabled"), as configured by the
ProxySet_EnableProxyKeepAlive parameter (see Configuring Proxy
Sets).
Address
Displays the IP address of the proxy server. This can be the IP
address as configured in dotted-decimal notation for the Proxy Set, or
the resolved IP address of a DNS query if an FQDN is configured for
the Proxy Set. IP addresses resolved from FQDNs are displayed as
"<FQDN name>(<resolved IP address>)", for example,
"abc.com(10.8.6.80)". The IP address that is currently used for routing
is indicated with an asterisk, for example, "10.8.6.89(*)".
If the FQDN failed to be resolved, only the FQDN name is displayed
(e.g., "abc.com").
Priority
Displays the priority of IP addresses resolved from FQDNs.
Note: The field is applicable only to Proxy Sets configured with
FQDNs.
Weight
Displays the weight of IP addresses resolved from FQDNs.
Note: The field is applicable only to Proxy Sets configured with
FQDNs.
Success Count
Displays the total number of successful keep-alive messages (by SIP
OPTIONS) sent by the device to the proxy.
Failure Count
Displays the total number of failed keep-alive messages (by SIP
OPTIONS) sent by the device to the proxy.
Status
Displays the status of the Proxy Set and its' proxy servers.
"ONLINE":
Proxy Set ID row: At least one proxy is online as determined
by the device's keep-alive feature. The status is also
"ONLINE" for IP addresses resolved from DNS queries even if
keep-alive is disabled.
Proxy server rows (if multiple addresses): The proxy server is
online as determined by the device's keep-alive feature.
"OFFLINE": The proxy is offline as determined by the device's
keep-alive feature and the Proxy Set is configured for Homing
('Redundancy Mode' parameter) or enabled for load balancing
('Proxy Load Balancing Method' parameter):
Homing: The proxy is the main proxy, but the keep-alive has
failed.
Load balancing: The keep-alive for the proxy has failed.
"NOT RESOLVED": Proxy address is configured as an FQDN, but
the DNS resolution has failed.
Empty field: Keep-alive for the proxy is disabled or the device has
yet to send a keep-alive to the proxy.
